Models PRO-Y3VL to PRO-Y4VL & PRO-Y3VH to PRO-Y6VH
This comprehensive range of professional series yagi antennas are designed for directional point-to-point applications in the VHF bands. They are designed to be used in the most rugged environments and to withstand harsh weather conditions. They can be used for either vertical or horizontal polarisation. Please specify polarisation when ordering.
The yagis are constructed from extruded Series 6000 silver anodised aluminium with the clamps being cast aluminium and fitted with stainless steel hardware.
Nominal feed impedance is 50 ohms with the matching circuit within the sealed driven element. The feed line is typically RG213 coaxial cable. Some models are however fitted with a 75 ohm coaxial cable which acts as an impedance transformer.
Please note: Do not alter the cable length.
All elements are DC grounded.
