Our coaxial 1/2w aerials provide high performance in the 700-1000 MHz bands. A range of models are available across this frequency range.
Like our heavy duty 1/2w and mini 1/2w models, the coaxial 1/2w aerial operates without the need for a ground plane. This feature allows them to be mounted in a convenient position on a vehicle or base station site.
The radiator is a stainless steel collinear element finished in black epoxy, giving 3dB gain. The coaxial matching section is housed inside a slim fibreglass tube which is capped with nickel plated brass fittings. The aerial is fitted with low loss cable as standard, which enters through the 12mm mounting stud.
A 6dB element is available on request (WCELCOL6).
A range of brackets is available for mounting.
A colour coding band for model identification is fitted to the coax cable at the mounting stud.
